High Performance Butterfly Valve is a true marvel of engineering, designed to deliver exceptional performance and reliability in the most demanding industrial applications. As one of the leading butterfly valve manufacturers, we pride ourselves on delivering the highest quality products at competitive prices.
Featuring a Double Offset design, our High Performance Butterfly Valve is the perfect choice for applications that demand precise control, high flow rates, and minimal pressure drop. With its superior performance and durability, this valve has become the go-to choice for industries ranging from chemical processing and power generation to water treatment and more.
D373H and D373Y High Performance Butterfly Valves adopt precise J-shaped elastic seal ring and three-eccentric multi-layer metal hard seal structure, which are widely used in metallurgy, power, petrochemical, water supply and drainage and municipal administration with medium temperature ≤425 It is used for regulating flow and carrying fluid in industrial pipelines such as construction.
Body Materials:Carbon Steel,Stainless Steel,Nickel Aluminum Bronze,alloy steel,etc
Nominal diameter:2 - 60" (50 - 1500mm)
Working pressure (MPa)：Class 150 to Class 900,PN1.0~4.0 ,10K-20K
Applicable temperature (℃)：≤300
Applicable medium：Water, oil, steam, etc.
End type：Wafer, lugged, flanged
Operation：Wench, Worm Gear, Electric, Pneumatic,etc
Body Style：Wafer, Lug and Double Flanged
Features：
1. The High Performance Butterfly Valve adopts a three-eccentric sealing structure, the valve seat and the butterfly plate have almost no wear, and have a tighter sealing function.
2. The sealing ring is made of stainless steel, which has the dual advantages of metal hard seal and elastic seal. It has excellent sealing performance under low and high temperature conditions, and has the characteristics of corrosion resistance and long service life.
3. The sealing surface of the butterfly plate adopts surfacing cobalt-based hard alloy, and the sealing surface is wear-resistant and has a long service life.
4. Large size butterfly board adopts quilting structure, high strength, large flow area, small flow resistance.
5. Wafer type hard seal butterfly valve has a bidirectional sealing function, which is not restricted by the flow direction of the medium during installation, nor is it affected by the position of the space, and can be installed in any direction.
6. The driving device can be installed in multiple stations (rotation 90 ° or 180 °), which is convenient for users.
